| Multiplexer Module |
|
| Number of sampling points: |
2 ... 24 |
| Purging of sample lines: |
continuously, ca. 40 ... 80 l/h for each channel |
| Flow control: |
Flow meters with alarm sensors for low flow |
| Heating of valve unit: |
approx. 70 °C |
| Sample line connectors: |
fittings for 4 mm i.d./ 6 mm o.d. tubing |
| Valves: |
minimum dead volume |
| Measuring duration: |
45 sec ... 99 minutes, adjustable separately for each channel |
Detector |
|
| Measuring principle: |
UV absorption at 253,7 nm |
| Type for standard range: |
Mercury-Vapor-Monitor VM-3000 |
Measuring range
(standard): |
0.1 to 100 µg/m³; 1 to 1000 µg/m³; 1 to 2000 µg/m³ |
| Type for low range: |
Mercury Ultratracer UT-3000 |
| Measuring range (low range): |
0.01 to 50 µg/m³ |
| Sample flow: |
ca. 80 l/h |
| PC connection: |
serial protocol RS 232; connection by cable (optionally by fibre optic cable);
modbus RTU; ethernet |
Mechanical |
|
| Cabinet: |
metal, protection standard IP 55 (NEMA 4X, others as an option) |
| Dimensions: |
from 553 x 600 x 500 mm (WxHxD) to 800 x 2000 x 600 mm; according to channel number and optional equipment (air conditioning) |
| Weight: |
approx. 35 - 175 kg; depending on number of channels and optional equipment |
Software |
|
| System requirement: |
PC with Windows XP, Vista |
| Display of measuring data: |
actual readings numerically, filed data as time-concentration graphs |
 |
